BQ reaming shell is a part of wireline drilling system. BQ reaming shell is mounted between outer tube and diamond bit. when drilling,the diameter of the drill hole is gradually reduced and the drill hole is slightly tapered. This situation is caused by the radial wear of the diamond bit. So the reaming shell is needed.The main function of reaming shell is to keep the drill hole size to the nominal diameter. To let the new changed diamond bit to be lowered into the bottom of the drill hole without getting stuck. Another function of reaming shell is to stabilize the core barrel and prevent the swing.

CGEO mainly offers three types of BQ reaming shells:

                                                                                      -BQ Impregnated Diamond Reaming Shells(IMP R/M)

                                                                                -BQ TSP Surface Set Diamond Reaming Shells(TSP SS R/M)

                                                                                -BQ Natural Diamond Surface Set Reaming Shells(ND SS R/M)

BQ REAMING SHELL OVERVIEW

BQ REAMINGS SHELL SIZE SPECIFICATIONS

NOTE:

     *BQ IMP reaming shell,BQ TSP SS reaming shell, BQ ND SS reaming shell are all available

    **other type of BQ reaming shell could be customized as requests

   ***Other size of BQ reaming shells are also available

BQ REAMING SHELL TYPE OPTIONS

REFERENCE PART#

C4064589 C4064555 C4062922 C4063823 C4062858

C3760955422 C3702636700

REFERENCE PHOTOS
