HRQ wireline drill rod play an important part in H size wireline drilling. It provides the channel for HQ inner tube assembly. It also transits the torque, drill pressure in complex and harsh conditions.

HRQ wireline drill rod tubing

●High quality alloy steel tubing

●Good concentricity, straightness and heat treatment

●Tubing properties meet the industry standard

HRQ wireline drill rod thread

●Improved HRQ tapered, course threads (3 threads per inch) ,increased taper and a reverse angle load flank provides an interlocking joint with increased strength and anti-jamming for easier make-up.

●Load efficiency of 50% provides sufficient strength for most drilling conditions

HRQ wireline drill rod heat treatment

●Provides higher material strength

●Whole rod Heat treated significantly increases rod life

HRQ wireline drill rod case hardening

●HRQ Pin thread crest is hardened to nominal 50-55 HRC to eliminate damaging’adhesion’ wear

●Eliminates the transfer of wear material back and forth as seen between threads of equal hardness, leading to large scale galling and joint seizing

HRQ WIRELINE DRILL ROD OVERVIEW

HRQ WIRELINE DRILL ROD THREAD PROFILE

HRQ WIRELINE DRILL ROD PARAMETERS

HRQ WIRELINE DRILL RODS BUNDLE SPECIFICATIONS

HRQ WIRELINE DRILL RODS CONTAINER SHIPMENTS

REFERENCE PART#

C306243 C3541310 C3541558 C3541381 C3541342 C3545071 C3760014026 C3760014027 C3760014028 C3760014023 C3760014024 C3760014025

REFERENCE PHOTOS
