BRQ wireline drill rod play an important in B size wireline drilling. It provides the channel for BQ inner tube assembly. It also transits the torque, drill pressure in complex and harsh conditions.

BRQ wireline drill rod tubing

●High quality alloy steel tubing

●good concentricity, straightness and heat treatment

●tubing properties meet the industry standard

BRQ wireline drill rod thread

●Typical BRQ tapered, course threads (3 threads per inch) provides easy make and break

●Load efficiency of 30% provides sufficient strength for most drilling conditions

BRQ wireline drill rod heat treatment

●Provides higher material strength

●Whole rod Heat treated significantly increases rod life

BRQ wireline drill rod case hardening

●BRQ Pin thread crest is hardened to nominal 50-55 HRC to eliminate damaging ‘adhesion’ wear

●Eliminates the transfer of wear material back and forth as seen between threads of equal hardness, leading to large scale galling and joint seizing

BRQ WIRELINE DRILL ROD OVERVIEW

BRQ WIRELINE DRILL ROD THREAD PROFILE

BRQ WIRELINE DRILL ROD PARAMETERS

BRQ WIRELINE DRILL RODS BUNDLE SPECIFICATIONS

BRQ WIRELINE DRILL RODS CONTAINER SHIPMENTS

REFERENCE PART#

C306238 C3541308 C3543582 C3541555 C3541378 C3541340 3545301 C3760014014 C3760014015 C3760014016 C3760014011 C3760014012 C3760014013

REFERENCE PHOTOS
