PW casing shoe

PW PWT casing shoe

PW PWT casing shoes PW PWT diamond casing shoe PW PWT casing bit

Description
Inquiry

PW PWT casing shoe is a part of casing system.The casing shoes are threaded to the end of the outer drill string for penetration through overburden. It helps in seating the outer drill string into the bedrock, providing a tight seal for the drilling fluids to return to the surface. PW PWT casing shoe can be used to ream the casing downward when advancing a casing string in an existing hole with the rod string still in place.

PW PWT casing shoes are heavy duty diamond products which can match up to the toughest formations. With the use of very resilient matrix to optimize diamond retention, they will hold up in very abrasive, unfriendly formations.

PW PWT CASING SHOE OVERVIEW

PW CASING SHOE OVERVIEW.jpg

PW CASING SHOE SIZE SPECIFICATIONS

Casing Shoe Size	Outside Set Diameter		Inside Set Diameter
	mm	inch	mm	inch
W/WT Series Casing Shoe
PW/PWT	143.40	5.646	123.40	4.858
